Description
Product Information
The 3M Purification Inc. 1ZMS3 Sanitary T-Line Filter Housing is designed for critical clarification and sterile filtration applications in the pharmaceutical industry. Made from high-quality 316L stainless steel, it accommodates one code 7 style filter element with double 226 o-rings and bayonet locking tabs, available in 10″ or 30″ lengths. This filter housing features 1/2″ sanitary vent and drain ports, 1 1/2″ sanitary gauge port, and 1″ sanitary inlet and outlet connections, ensuring versatile use with liquid or gas service. It can be easily cleaned in place (CIP), steamed in place (SIP), or hot water sanitized. With a near-new condition, it boasts little to no cosmetic damage and meets stringent industry standards. Manufactured with precision in Taiwan, this filter housing is suitable for life sciences applications with a maximum operating temperature of 100°C (212°F).
Key Features
- 316L stainless steel construction
- Accommodates code 7 style filter elements
- Accepts filters in 10″ or 30″ lengths
- Sanitary vent, drain, and gauge ports
- 1″ sanitary inlet and outlet connections
- Clean-in-place (CIP) and steam-in-place (SIP) capabilities
- Maximum operating temperature: 100°C (212°F)
Specifications
- Brand: 3M Purification Inc.
- Model: 1ZMS3
- Material: 316L stainless steel
- Filter Element Type: Code 7 style with double 226 o-rings
- Filter Length: 10″ or 30″
- Sanitary Ports: 1/2″ vent and drain, 1 1/2″ gauge
- Inlet/Outlet Connections: 1″ sanitary
- Operating Temperature: Max 100°C (212°F)
- Applications: Critical clarification, sterile filtration
- Manufactured Country: Taiwan
Weight
Imperial: 18.0 Pounds
Metric: 8.16 Kilograms
Shipping Dimensions
Imperial: 10.8 lb x 10.8 lb x 55.2 lb
Metric: 27.43 cm x 27.43 cm x 140.21 cm
Harmonized Code
84212100
Harmonized Code Details
84212100 – Water filtering or purifying machinery and apparatus. This code applies as the equipment is related to filtration technology used in sanitary and pharmaceutical contexts.
