Description
Product Information
The ABB ACH580-PCR-034A-4 is an advanced HVAC AC Drive tailored for efficient and reliable operation in a range of applications. Manufactured in January 2022 in the USA, this drive offers 25HP with a voltage of 480V and current of 34.0A. It is designed for wall-mounting with a user-friendly control panel, including optional Bluetooth for enhanced remote accessibility. The ACH580 series promotes energy efficiency and is equipped for seamless integration with industry-standard HVAC communication protocols such as BACnet MS/TP, Johnson Controls N2, and Modbus RTU. Built-in PID controllers provide superior performance in fans, pumps, compressors, air-handling units, and chillers, making the drive suitable for deployment in hospitals, data centers, shopping centers, and more. The product is in new, unused condition with minor cosmetic scratches and dents, supplied in an unopened box.
Technician comment
New in unopened box. See photos
Key Features
- 25HP AC Drive
- 480V Voltage
- 34.0A Current
- Wall-mounted design
- User-friendly control panel with Bluetooth option
- Support for BACnet MS/TP, Johnson Controls N2, Modbus RTU
- Built-in PID Controllers
Specifications
- Rated Power: 25HP
- Voltage: 480V
- Current: 34.0A
- Frequency: 50Hz/60Hz
- Wall-mounted
- Communication Protocols: BACnet MS/TP, Johnson Controls N2, Modbus RTU
- Bluetooth Option for Enhanced Access
- Built-in PID Controllers for Enhanced Control
Weight
Imperial: 96.0 Pounds
Metric: 43.54 Kilograms
Shipping Dimensions
Imperial: 18.0 lb x 64.8 lb x 24.0 lb
Metric: 45.72 cm x 164.59 cm x 60.96 cm
Harmonized Code
85044084
Harmonized Code Details
85044084 – Static converters; this code applies to electrical equipment and includes static converters such as AC drives used for electric motor control.
