Description
Description
Features
- Helps ensure compliance with current and future OSHA regulations
- Portability provides easy mobility around the lab or office
- Unique prefilter allows for recovery of precious metals
- Blower motor rated at 100,000 continuous duty hours
- Powder paint coated paint finish inside and out
- Quiet operation compared to standard dust collectors
- Optional filter medias are available for countless applications including Chemical Adsorption Modules, as well as ULPA and HEPA filters
- All electrical components and filter media are UL and CE approved
- Three-year warranty
Specs
Cabinet:
18-gauge steel, polyurethane powder coated paint inside and out.
Cabinet Dimensions:
12-1/2” W x 33-1/4” H x 12-1/2” D
Weight:
Approx. 30 lbs with standard filter package (plus additional weight for source capture options)
Blower (UL and CE Certified for US and Canada):
350W, 2.8 AMPS, 120/1/60, 2000 RPM, variable speed control, and power cord with plug.
Typical Motor Life:
100,000 hours (depending on operating conditions, including ambient temperature, duty cycle, etc.)
Rated Fan Performance:
350 CFM @ .5” E.S.P., 240 CFM @ 2.0” E.S.P., 100 CFM @ 2.75”E.S.P.
Velocity at Extractor Arm Inlet:
3500 FPM per arm
Noise Level:
65 dBA
